Applications:
Y83 series metal hydraulic baler is capable of extruding various metal leftover materials, steel paring, waste copper, aluminum, copper, stainless steel and scraped car materials into qualified charging such as square column, cylinder, octagon body and other sharps, in a bid to reduce transportation & refining costs, and increase transportation speed. Such baler is mainly used in steel plants, reclamation & processing industry and nonferrous & ferrous metal refining industry.
| No. | Model | Nominal Force | Chamber size | Bale section | Power | Operation |
|---|---|---|---|---|---|---|
| 1 | Y83/T-160A | 1600kN/160t | 1600×1000×800mm | 350×350mm | 22/30kW | Manual Valve operation |
| Y83/T-160B | 1600×1200×800mm | 400×400mm | ||||
| 2 | Y83/T-200A | 2000kN/200t | 1600×1000×800mm | 400×400mm | 30/37/44kW | Manual Valve operationorPLC contrl |
| Y83/T-200B | 1600×1200×800mm | 400×400mm | ||||
| Y83/T-200D | 1600×1200×900mm | 400×400mm | ||||
| Y83/T-200E | 1800×1400×800mm | 450×450mm | ||||
| Y83/T-200F | 1800×1400×900mm | 450×450mm | ||||
| 3 | Y83/T-250A | 2500kN/250t | 2000×1400×900mm | 450×450mm | 44/60kW | |
| Y83/T-250B | 2000×1400×1000mm | 500×500mm | ||||
| Y83/T-250C | 2000×1750×1200mm | 500×600mm | ||||
| Y83/T-250D | 2500×1750×1200mm | 500×600mm | ||||
| Y83/T-250E | 2000×1750×1200mm | 600×600mm | 60/74kW | |||
| 4 | Y83/T-315A | 3150kN/315t | 2600×1750×1200mm | 600×600mm | ||
| 5 | Y83/T-400 | 4000kN/400t | 3000×2500×1300mm | 600×600mm | 90kW | Manual Valve operationorPLC contrl |
|
3500×3000×1300mm |
||||||
| 6 | Y83/T-500 | 5000kN/500t | 3000×2500×1300mm | 700×700mm | 135kW | Manual Valve operationorPLC contrl |
|
3500×3000×1300mm |
||||||
| 4000×3500×1300mm | ||||||
| 7 | Y83/T-800 | 8000kN/800t | 3000×2500×1300mm |
700×700mm |
225kW | PLC contrl |
| 3500×3000×1300mm | ||||||
| 4000×3500×1300mm |
